Metal Template: Doberman
-
Size90 x 33 x 56 cm
-
Sheet size106 x 125 cm
Files included:
- DXF files for laser cutting
- PDF file showing bend angles
- PDF welding instruction
Features:
-
metal sheet 1.5 mm thick;
-
drawing on the front side of the assembled model;
-
most of the welds are on the front side;
-
total length of cutting line: 51 m.;
-
the cutting contours of the parts contain holes in the corners to relieve stress and contain notches to define fold lines without engraving;
-
fold lines for engraving are marked in different colors according to the bending direction: UP – yellow, DOWN – red.
What to do
- Cut pieces with laser
- Engrave fold lines and part numbers if you wish
- Use a sheet bending machine
- Weld parts
- Grind welds
- Design the surface as desired
We know how to make a polygonal metal figure. Here you can buy and download drawing and instructions for the creation of metal sculpture.
The set of drawings for making a metal dragon head contains four types of DXF files to choose from:
- DXF files with the file name "...-Nesting-..."
contain only cutting lines (without engraving). We made notches and cutouts in the contours of the parts. Notches are used to determine the location of fold lines. Cutouts are used to relieve stress in the corners of the bends. - DXF files with the signature "...-NestingLabel-..."
contain the same cutting lines (with notches and cutouts), and elements for engraving — fold lines and part numbers. DOWN fold lines are marked in red; UP fold lines are marked in yellow. - A folder with files where the parts are not arranged on a sheet, and each part is saved as a separate DXF file.
Designer: Rim Shamsin. Use of our intellectual property for profit is prohibited. All rights reserved.
Delivery and payment
-
A link with a downloadable file will be emailed to you within an hour following your online payment.
-
Payment method - credit card and other methods provided by Stripe or PayPal
