Polygonal Paper — Metal Template: Snake

Size

229 x 222 x 206 cm
Sheet size

4 pcs.: 125 x 250 см + 1 pcs.: 125 х 81 cm

Files included:

DXF files for laser cutting
PDF file showing bend angles
PDF welding instruction

Features:

metal sheet 1.5 mm thick;
drawing on the front side of the assembled model;
most of the welds are on the front side;
total length of cutting line: 175 m.;
the cutting contours of the parts contain holes in the corners to relieve stress and contain notches to define fold lines without engraving;
fold lines for engraving are marked in different colors according to the bending direction: UP – yellow, DOWN – red.

140 $

Other product formats:

Cut pieces with laser
Engrave fold lines and part numbers if you wish
Use a sheet bending machine
Weld parts
Grind welds
Design the surface as desired

We know how to make a polygonal sheet metal figure. Here you can buy and download drawing and instructions for the creation of metal low poly sculpture.

The set of drawings for making a metal dragon head contains three types of DXF files to choose from:

DXF files with the file name "...-Nesting-..."
contain only cutting lines (without engraving). We made notches and cutouts in the contours of the parts. Notches are used to determine the location of fold lines. Cutouts are used to relieve stress in the corners of the bends.
DXF files with the signature "...-NestingLabel-..."
contain the same cutting lines (with notches and cutouts), and elements for engraving — fold lines and part numbers. DOWN fold lines are marked in red; UP fold lines are marked in yellow.
DXF files with the signature "...-BendingTabs-..."
are supplemented with technological allowances for the bend. Triangular protrusions are built into the cutting contour of the parts. They are located in those places where the bend is at an angle of the edge, so that the metal does not turn out in places with a narrow capture field. Before assembly, bending tabs must be cut off with a grinder.

Designer: Dmitry Glazkov.
Use of our intellectual property for profit is prohibited. All rights reserved.
